Chain Conveyors

Chain conveyor is the machine thanks which Trasmec became the most famous conveyors producer in the world. The strong design of these machines multiplied by long experience developed during 50 years of wood industry existence has permitted Trasmec to be proud to deliver in average 100 chain conveyors per year to the most important wood board producers.

The long-life design allows to convey any type of wood product, as wood chips, flakes and strand.
The conveyors in stainless steel AISI304 (for acidic material), with bottom covered in HARDOX 450 (wearing material) or covered in high density plastic material (for blended flake) are also available.

All chain links are subject to very strict quality checks and are made for resisting to high loads (up to 840 kN) and high wearing conditions (18MnCrB5), available in pitches of 142 or 260 mm (“Panzer” chain link).

High wearing resistance to friction due to sliding is guaranteed by wear strips in manganese, available with a thickness of 12 or 20 mm for increasing the working life duration.

For relatively small/medium capacities (up to 500 cubic meters per hour), Trasmec suggests single chain conveyors, with sizes from of 11 to 50 inches.
For high capacities, Trasmec suggests however single chain conveyors with Panzer chain or double chain conveyors, with sizes from 24 to 80 inches (up to 1000 cubic meter per hour).

Trasmec can also offer different types of scrapers, depending on the size of the material.

All our chain conveyors are designed to be ATEX certified.
